A brass quick connect female coupler is a type of connector used in plumbing and fluid transfer applications. Here are some key features and benefits:
Features:
· Body Material: Brass material for corrosion resistance
· Spring Material: 304 Stainless Steel
· Locking Ball Material: 316 Stainless Steel
· Self Sealing Poppet Valve Seals Excellent Under High and Low Pressures
· Interchangeable with all ISO 7241 B series couplings
· Nominal Flow Rate: 12 GPM
· Max Flow Rate: 23.78 GPM
· Seal Type: Viton FKM
· Temperature Range: -15°F to +400°F
|
Body Size(in) |
1/8 |
1/4 |
3/8 |
1/2 |
3/4 |
1 |
1-1/4 |
1-1/2 |
2 |
|
Rated Pressure(PSI) |
1000 |
1000 |
1000 |
1000 |
1000 |
1000 |
800 |
800 |
800 |
|
Rated Flow(GPM) |
1 |
3 |
6 |
12 |
28 |
50 |
75 |
100 |
150 |
|
Temperature Range |
-20℃ to +120℃ |
||||||||
|
Standard seal material |
NBR |
||||||||
Applications:
KZD couplings, are used across the spectrum of hydraulic applications. These Double Shut-Offcouplings can be found anywhere that fluid transfer lines need to be connected and disconnected for operation or maintenance of equipment, and a loss of fluid is undesirable. Primarily used with hydraulic fluid. KZD couplings are also used with chemicals, water, steam, and some gases.
Installation:
Preparation:
Ensure that both the coupler and the hose or fitting it connects to are clean and free of debris.
Connection:
For threaded connections: Apply Teflon tape to the threads of the male fitting for a tight seal. Screw the female coupler onto the fitting until secure, but do not overtighten.
For barbed connections: Push the hose onto the barbed end of the coupler and secure it with a hose clamp to prevent leakage.
For push-to-connect: Simply push the hose into the coupler until it clicks into place.
Maintenance:
Inspection:
Regularly check for wear, cracks, or signs of corrosion. Inspect O-rings and seals for any damage.
Cleaning:
Rinse with water to remove any debris or contaminants. Avoid using harsh chemicals that could corrode the brass.
Lubrication:
Occasionally, a light application of silicone grease on the O-rings can help maintain a good seal and prolong the life of the coupler.
Storage:
If not in use for extended periods, store in a dry place to prevent moisture-related corrosion.
